Barber Electric “Type 3 Screw Cover Troughs” and the related fittings are designed to house electrical controls and instruments in area which may be regularly hosed down or are otherwise very wet.

The 2-1/2 x 2-1/2, 4 x 4, and 6 x 6 wireway sizes are made from 16 gauge steel and are available with or without electrical knockouts. The 8 x 8, 10 x 10, and 12 x 12 wireway sizes are made from 14 gauge steel and are available without knockouts only. The covers are secured with stainless steel machine screws. These troughs have a galvanized finish. A powder coated finish is also available for these products upon request.

Barber Electric can supply holes, cutouts, special wireway sizes, special fittings, and other modifications. Please consult the factory for any special needs.



PDF (Click thumbnail to view full size):



Catalog #
Size (A x B x C)

Catalog #
Size (A x B x C)

B125SCWP
12 x 2.5 x 2.5

B188SCWP
12 x 8 x 8
B225SCWP
24 x 2.5 x 2.5

B288SCWP
24 x 8 x 8
B325SCWP
36 x 2.5 x 2.5

B388SCWP
36 x 8 x 8
B425SCWP
48 x 2.5 x 2.5

B488SCWP
48 x 8 x 8
B525SCWP
60 x 2.5 x 2.5

B588SCWP
60 x 8 x 8
B144SCWP
12 x 4 x 4

B12-10SCWP
12 x 10 x 10
B244SCWP
24 x 4 x 4

B24-10SCWP
24 x 10 x 10
B344SCWP
36 x 4 x 4

B36-10SCWP
36 x 10 x 10
B444SCWP
48 x 4 x 4

B48-10SCWP
48 x 10 x 10
B544SCWP
60 x 4 x 4

B60-10SCWP
60 x 10 x 10
B166SCWP
12 x 6 x 6

B12-12SCWP
12 x 12 x 12
B266SCWP
24 x 6 x 6

B24-12SCWP
24 x 12 x 12
B366SCWP
36 x 6 x 6

B36-12SCWP
36 x 12 x 12
B466SCWP
48 x 6 x 6

B48-12SCWP
48 x 12 x 12
B566SCWP
60 x 6 x 6

B60-12SCWP
60 x 12 x 12




Interactive 3D PDF (Click thumbnail to view and interact):
