Barber Electric “Type 3R Hinge Cover Enclosures” are designed for use as wiring boxes and junction boxes in outdoor installations. They are designed to protect the enclosed equipment against rain and sleet.

These enclosures are made from 16 and 14 gauge galvanized steel. A drip shield top and smooth, seamless sides prevent rain, snow, and sleet from entering the enclosure. The cover is hinged on the left side with a continuous hinge and is held shut by a padlockable pull catch. External feet are provided for mounting. These enclosures are studded for optional back panels. The standard finish for these enclosures is ANSI 61 gray polyester powder coat.

Barber Electric can supply holes, cutouts, special materials, special finishes, and many other modifications. Please consult the factory for any special needs.

PDFs (Click thumbnail to view full size):


Catalog #
Size (A x B x C)

B664RTHC
6 x 6 x 4
B884RTHC
8 x 8 x 4
B10104RTHC
10 x 10 x 4
B12124RTHC
12 x 12 x 12
B886RTHC
8 x 8 x 6
B10106RTHC
10 x 10 x 6
B12126RTHC
12 x 12 x 6
B12128RTHC
12 x 12 x 8
B15126RTHC
15 x 12 x 6
B18126RTHC
18 x 12 x 6





Catalog #
Size (A x B x C)

B18156RTHC
18 x 15 x 6
B18186RTHC
18 x 18 x 6
B24156RTHC
24 x 15 x 6
B24186RTHC
24 x 18 x 6
B18158RTHC
18 x 15 x 8
B18188RTHC
18 x 18 x 8
B24158RTHC
24 x 15 x 8
B24188RTHC
24 x 18 x 8
B181812RTHC
18 x 18 x 12
B241812RTHC
24 x 18 x 12





Catalog #
Size (A x B x C)

B242412RTHC
24 x 24 x 12
B302412RTHC
30 x 24 x 12
B303012RTHC
30 x 30 x 12
B363012RTHC
36 x 30 x 12
B363612RTHC
36 x 36 x 12
B423612RTHC
42 x 36 x 12






Interactive 3D PDFs (Click thumbnails to view and interact):
