Barber Electric “Type 4 Screw Cover Enclosures” are designed to house electrical controls and instruments in area which may be regularly hosed down or are otherwise very wet.

These enclosures are made from 14 gauge steel and have a strong and rigid construction. All seams are continuously welded and ground smooth and there are no holes or knockouts. Stainless steel captive screws are used to secure the gasketed cover. External feet are furnished for mounting. Collar studs are provided for mounting the optional panel. Panels must be ordered separately.

The standard finish for these enclosures is ANSI 61 gray polyester powder coat. Barber Electric can provide special finishes upon request.

PDF (Click thumbnail to view full size):


Catalog #
Size (A x B x C)

B664SCWPN4
6 x 6 x 4
B884SCWPN4
8 x 8 x 4
B10104SCWPN4
10 x 10 x 4
B12124SCWPN4
12 x 12 x 4
B886SCWPN4
8 x 8 x 6
B10106SCWPN4
10 x 10 x 6
B12126SCWPN4
12 x 12 x 6
B18186SCWPN4
18 x 18 x 6
B24246SCWPN4
24 x 24 x 6
B30306SCWPN4
30 x 30 x 6




Interactive 3D PDF (Click thumbnail to view and interact):
