Barber Electric “Type 4 Hinge Cover Troughs” are designed to house electrical controls and instruments in area which may be regularly hosed down or are otherwise very wet.

These enclosures are made from 14 gauge steel and have a strong and rigid construction. All seams are continuously welded and there are no holes or knockouts. A rolled lip is provided around three sides of the door. A stainless steel hinge is provided. Stainless steel clamps and machine screws are used to secure the gasketed cover. The standard finish for these enclosures is ANSI 61 gray polyester powder coat.

Barber Electric can supply holes, cutouts, special wireway sizes, special fittings, and other modifications. Please consult the factory for any special needs.

PDF (Click thumbnail to view full size):


Catalog #
Size (A x B x C)

Catalog #
Size (A x B x C)

15B125CHN4
12 x 2.5 x 2.5

15B188CHN4
12 x 8 x 8
15B225CHN4
24 x 2.5 x 2.5

15B288CHN4
24 x 8 x 8
15B325CHN4
36 x 2.5 x 2.5

15B388CHN4
36 x 8 x 8
15B425CHN4
48 x 2.5 x 2.5

15B488CHN4
48 x 8 x 8
15B525CHN4
60 x 2.5 x 2.5

15B588CHN4
60 x 8 x 8
15B144CHN4
12 x 4 x 4

15B12-10CHN4
12 x 10 x 10
15B244CHN4
24 x 4 x 4

15B24-10CHN4
24 x 10 x 10
15B344CHN4
36 x 4 x 4

15B36-10CHN4
36 x 10 x 10
15B444CHN4
48 x 4 x 4

15B48-10CHN4
48 x 10 x 10
15B544CHN4
60 x 4 x 4

15B60-10CHN4
60 x 10 x 10
15B166CHN4
12 x 6 x 6

15B12-12CHN4
12 x 12 x 12
15B266CHN4
24 x 6 x 6

15B24-12CHN4
24 x 12 x 12
15B366CHN4
36 x 6 x 6

15B36-12CHN4
36 x 12 x 12
15B466CHN4
48 x 6 x 6

15B48-12CHN4
48 x 12 x 12
15B566CHN4
60 x 6 x 6

15B60-12CHN4
60 x 12 x 12




Interactive 3D PDF (Click thumbnail to view and interact):
