Barber Electric “Type 3 Hinge Cover Weatherproof Enclosures” are used as wiring boxes, terminal boxes, and other similar applications. They can be used in many outdoor applications, as well as indoor applications which may be regularly hosed down or are otherwise very wet.

Barber Electric “Type 3 Hinge Cover Weatherproof Enclosures” are made from 14 and 12 gauge galvanized steel. All seams are continuously welded and there are no holes or knockouts. A gasket insures a watertight seal and the hinged door contains a padlock provision. A drip shield is welded across the top of the door for added protection.

The standard finish for these enclosures is ANSI 61 gray polyester powder coat. Barber Electric can provide holes, cutouts, mounting feet, special sizes, and many other modifications.

PDFs (Click thumbnail to view full size):


Catalog #
Size (A x B x C)

B664HCWP
6 x 6 x 4
B884HCWP
8 x 8 x 4
B10104HCWP
10 x 10 x 4
B12124HCWP
12 x 12 x 4
B16164HCWP
16 x 16 x 4
B666HCWP
6 x 6 x 6
B886HCWP
8 x 8 x 6
B10106HCWP
10 x 10 x 6
B12126HCWP
12 x 12 x 6
B16166HCWP
16 x 16 x 6





Catalog #
Size (A x B x C)

B18186HCWP
18 x 18 x 6
B20206HCWP
20 x 20 x 6
B24246HCWP
24 x 24 x 6
B30306HCWP
30 x 30 x 6
B12128HCWP
12 x 12 x 8
B18188HCWP
18 x 18 x 8
B20208HCWP
20 x 20 x 8
B24248HCWP
24 x 24 x 8
B30308HCWP
30 x 30 x 8
B303010HCWP
30 x 30 x 10


Interactive 3D PDFs (Click thumbnails to view and interact):
