Barber Electric “Type 4 Double Door Enclosures” are designed to house electrical controls and instruments in area which may be regularly hosed down or are otherwise very wet.

These enclosures are made form 12 gauge steel. All seams are continuously welded and there are no holes or knockouts. A rolled lip is provided on three sides of the door and around all sides of the enclosure opening. This lip increases strength and keeps dirt and liquid from dropping into the enclosure when the door is opened. Clamps are provided on three sides of each door to insure a water-tight seal with the neoprene gaskets. A heavy gauge continuous hinge supports each door. The center post is removable for easy panel installation. A hasp and staple are provided on each door for padlocking and each enclosure has a print pocket. All double door enclosures have heavy duty lifting eyes and X-form stiffeners. Collar studs are provided for mounting the optional panels. Panels must be ordered separately.

The standard finish for "Type 4 Hinge Cover Enclosures" is light grey. Barber Electric can provide special finishes upon request.

PDF (Click thumbnail to view full size):


Catalog #
Size (A x B x C)
Panel Size

7BDD48488
48 x 48 x 8
45 x 45
7BDD60488
60 x 48 x 8
57 x 45
7BDD484810
48 x 48 x 10
45 x 45
7BDD604810
60 x 48 x 10
57 x 45
7BDD484812
48 x 48 x 12
45 x 45
7BDD604812
60 x 48 x 12
57 x 45


Interactive 3D PDF (Click thumbnail to view and interact):
