Barber Electric "Large Oil Tight CH Enclosures" are designed to house electrical controls, terminals, and instruments. They provide protection from dust, dirt, oil, and water.

These enclosures are made from 14 gauge steel and have a strong, rigid construction. All seams are continuously welded and there are no holes or knockouts. The neoprene door gasket is attached with oil-resistant adhesive. A continuous hinge is provided on the long side. Body and door stiffeners are provided in larger enclosures. External feet are furnished for mounting the enclosure. Collar studs are provided for mounting the optional panel. Panels must be ordered separately.

The standard finish for these enclosures is ANSI 61 gray polyester powder coat. Barber Electric can provide holes, hubs, louvers, cutouts, special finishes and many other modifications to these enclosures.

PDFs (Click thumbnail to view full size):

Catalog #
Size (A x B x C)
Panel Size

2DB20167LP
20 x 16 x 7
17 x 13
2DB20207LP
20 x 20 x 7
17 x 17
2DB24207LP
24 x 20 x 7
21 x 17
2DB24247LP
24 x 24 x 7
21 x 21
2DB30207LP
30 x 20 x 7
27 x 17
2DB30247LP
30 x 24 x 7
30 x 21
2DB36247LP
36 x 24 x 7
33 x 21
2DB20169LP
20 x 16 x 9
17 x 13
2DB20209LP
20 x 20 x 9
17 x 17
2DB24249LP
24 x 24 x 9
21 x 21


Interactive 3D PDF (Click thumbnail to view and interact):
